This is an extension board for DL series Microcontroller board.

The Bluetooth module will be able to connect with system using IOS, Android and Windows.

Small dimension and power efficient which is very good for IOT implementation.

• Supply voltage : 1.8V to 3.3V
• Current : 5mA broadcast, 12mA SPP mode
• Default Pairing code: 1234
• Interface : Serial UART
• Bluetooth : SPP 3.0 + BLE 4.2
• working frequency band 2.4GHZ
• modulation mode GFSK
• maximum transmission power 5db
• Receiver sensitivity: -90dbm
• Transmission distance: 20 meters
• Dimension : 52mm by 21mm

Note: As this product is in development, final outlook may differ from the picture.

Do register your interest using the purchase options and leaving your email contact, we will keep you updated on the project and arrangement further with you once the product is ready for delivery.

For question or feedback please feel free to contact us using our contact page.
