Adjustable DC-DC boost (Step up) convertor module
Product Details
Non-isolated Adjustable DC-DC boost module.
• Input voltage : 3V to 32V
• Output voltage : Range higher than input, 5V to 40V
• Current: 4A peak, 2A Typical
• Power : 30W max
• Operating Freq: 400khz
• Output Ripple : Typical 50mV, greater at higher load.
• Dimension : 43mm * 21mm * 14mm
